Color Wired Camera, A-PAL110C
110° Wired Color Camera - PAL Format
The wired camera is a waterproof, color CCD camera with audio. The A-PAL110C has 110 degrees of viewing angle and 28 infrared illuminators for night vision up to 32 feet. The CabCAM camera has day/night sensors for automatic light adjustment.
Image Device 1/3" Sharp Sensor CCD White Balance Auto
TV System PAL Electronic Shutter 1/50 PAL
Effective Pixels
512 x 492 | 512 x 582
BLC Auto
Sensing Area 4.9mm x 3.7mm Current Consumption Max 400mA
Sync. System Internal Power Supply DC12V
Horizontal Resolution 420 TV Lines Operating Temperature -20°C ~ 70°C
Minimum Illumination 0 Lux / F2 Storage Temperature -40°C ~ 85°C
Video Output 1.0Vp-p, 75Ohm Lens f=2.8mm / f=2.0
AGC Auto Lens Angle 120°
S/N Radio Better than 48db Audio Optional
